| Brand Name : | KOCHFENCE |
| Model Number : | KF-180 |
| Certification : | ISO9001，CE，SGS |
| Price : | Negotiable |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 50 tons/ Day |
| Delivery Time : | 5-8 working days |
Beautiful appearance,economical cost and practicality,and convenient construction.
Uses:mainly used in park,lawn border ,railway ,highway,prisons and other aspects.
Blade style
| Model | Thickness | Wire Dia | Length | Width | Spacing |
| BTO-10 | 0.5mm | 2.5mm | 12mm | 13mm | 26mm |
| BTO-12 | 0.5mm | 2.5mm | 12mm | 15mm | 26mm |
| BTO-18 | 0.5mm | 2.5mm | 18mm | 15mm | 33mm |
| BTO-22 | 0.5mm | 2.5mm | 22mm | 15mm | 34mm |
| BTO-28 | 0.5mm | 2.5mm | 28mm | 15mm | 34mm |
| BTO-30 | 0.5mm | 2.5mm | 30mm | 18mm | 34mm |
| CBT-60 | 0.6mm | 2.5mm | 60mm | 32mm | 96mm |
| CBT-65 | 0.6mm | 2.5mm | 65mm | 21mm | 100mm |
Single loop razor barbed wire
| single loop razor barbed wire(single coil) | ||||
| Out diameter | No. of loops | Standard cover length | Blade Style | Remark |
| 450mm | 33 | 7-8M | CBT-60.65 | Single coil |
| 500mm | 56 | 12-13M | CBT-60.65 | Single coil |
| 700mm | 56 | 13-14M | CBT60.65 | Single coil |
| 960mm | 56 | 14-15M | CBT60.65 | Single coil |
Cross type razor bared wire:
| Cross type razor barbed wire (double loops) | ||||
| 450mm | 56 | 8-9M(3CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 500mm | 56 | 9-10M(3CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 600mm | 56 | 10-11M(3CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 600mm | 56 | 8-10M(5CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 700mm | 56 | 10-12(5CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 800mm | 56 | 11-13(5CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 900mm | 56 | 12-14(5CLIPS) | BTO-10.12.18.22.28.30. | Cross type |
| 960mm | 56 | 13-15(5CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 980mm | 56 | 14-16(5CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
Flat warp razor barbed wire
| width | loops/roll | length/roll | blade type |
| 450mm | 126 | 16M | BTO-10,12,18,22,28,30 |
| 600mm | 95 | 16M | BTO-10,12,18,22,28,30 |
| 900mm | 63 | 16M | BTO-10,12,18,22,28,30 |
| 1100mm | 51 | 16M | BTO-10,12,18,22,28,30 |
Razor barbed wire package:woven bag,in pallet,in bulk
Pre-sale service:
1.Providing sample
2.According to your size processing
3.Respond promptly
After-sales service :
1.After placing orders will be timely feedback to track the progress of related production, shipment
2.Accordance with the stipulated time of shipment delivery, guaranteed delivery and supply capacity.
3.Encounter any quality problems can always contact us, we will promptly communicate timely
|
|
